Masada Bottle Jack

STANDRAT LOW PROFILE BOTTLE JACK SPECIFICATION (Dongkrak Bottol)

Rigidly adhering to JIS standards, Masada jacks boast excellent quality, modern design, and extremely high precision. These qualities have earned them a worldwide reputation for reliability.

Of welded construction throughout, Masada hydraulic jacks are light and durable. Masada’s unique base forging method increases resistance to high pressure and gives a degree of durability and performance not found in any other comparable products. As a result, many automobile manufactures choose Masada hydraulic jacks for their products. Among Masada’s clients are Isuzu, Mitsubishi, Fuso, Hino, Nissan Diesel, and Mazda.

Widely used in various fields such as machinery, construction, and Automotive industry.

All models work both in vertical and horizontal positions. All models have common release stem and valve assemblies, many other parts are also interchangeable from model to model.

Where applicable Masada jacks are certified to Australian Standards AS/NZS 2693-1993.

Full ranges of capacities are available from 2,000Kg to 100,000Kg see chart for sizes and specifications.

Specification / Model	Capacity (ton)	Min. Height (mm)	Lift (mm)	Extension Screw Height (mm)	Max. Height (mm)	Weight (kg)
MS - 2	2	180	115	50	345	2. 2
MS - 3	3	190	115	60	365	2. 4
MS - 5	5	200	120	70	390	4. 6
MH - 10	10	240	150	80	470	7. 9
MH - 15	15	265	165	80	510	10. 4
MH - 20	20	270	160	-	430	12. 2
MH - 30 Y	30	280	160	-	440	18. 5
MH - 50Y	50	305	170	-	475	37. 0
MH - 100Y	100	305	145	-	450	93. 0

Service Jack

SERVICE JACK SPECIFICATIONS

1. Quality is the criteria with this equipment, a foot pedal-pumping device to raise the saddle to the load quickly.
2. Rear wheel castors are fitted to balance the weight of the jack enabling the operator to move the jack in any direction using the lockable handle and footplate on the rear of the jack.
3. Built-in automatic safety valves prevent overloading.
4. Overall construction of selected steels gives long and trouble free use.

SERVICE JACK SPECIFICATIONS (Dongkrak Buaya)

Specification / Model	Capacity (ton)	Min. Height (mm)	Lift (mm)	Extension Screw Height (mm)	Max. Height (mm)	Weight (kg)
SJ - 20S	2	113	360	473	150	33
SJ - 20L	2	121	360	481	160	45
SJ - 30 H	3	126	480	606	190	65
SJ - 50 H	5	150	410	560	200	85
SJ - 100 H	10	160	400	560	250	135

Hydraulic Press

HYDRAULIC PRES SPECIFICATIONS (Hydraulic Pres)

pecification / Model	Capacity (ton)	Ram Stroke (mm)	Screw Stroke (mm)	Frame Clearance (mm)	Table Clearance (mm)	Table Movement (mm)	Overall Height (mm)	Base Size (mm)	Weight Die (kg)
MHP - 15	15	160	120	600	142	700	1630	860X600	150
MHP - 35	35	140	100	610	185	750	1750	910X775	250
MHP - 60	60	150	150	1100	234	600	1920	1450X1090	800

Loking Type Jack

LOCKING TYPE JACK SPECIFICATIONS

Specification / Model	Capacity (ton)	Min. Height (mm)	Lift (mm)	Extension Screw Height (mm)	Max. Height (mm)	Weight (kg)
MH - 5 LS	5	225	120	70	415	6. 3
MH - 10 LS	10	300	165	80	545	13. 0
MH - 15 LS	15	310	160	80	550	15. 3
MH - 20 L	20	310	160	-	470	15. 3

Jack With Pressure Gauge

JACK WITH PRESSURE GAUGE SPECIFICATIONS

Specification / Model	Capacity (ton)	Min. Height (mm)	Lift (mm)	Extension Screw Height (mm)	Max. Height (mm)	Weight (kg)
MH – 7 P	7	203	120	70	393	7. 5
MH - 10 P	10	240	150	80	470	9. 9
MH - 15 P	15	265	165	80	510	12. 8
MH - 20 P	20	270	160	-	430	14. 3
MH - 30 P	30	280	160	-	440	23. 3
MH - 50 PY	50	305	170	-	475	37
MH - 100 PY	100	305	145	-	450	91
